1756-LSC8XIB8I Allen-Bradley

Series#: AllenBradley

Product Details

High-performance 1756-LSC8XIB8I Allen-Bradley ControlLogix analog input module for precision industrial automation.
Offers 8 isolated differential input channels with 16-bit resolution for accurate signal acquisition.
Supports multiple signal types: ±10V, 0-10V, 0-20mA, and 4-20mA, with field-side isolation up to 500V AC/DC.
Designed for seamless integration into ControlLogix chassis, ensuring robust and reliable operation in harsh environments.
Includes built-in diagnostic LEDs for easy troubleshooting and status monitoring.
Compliant with industry standards for safety and performance, backed by Rockwell Automation quality.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The Allen-Bradley 1756-LSC8XIB8I is a high-density analog input module engineered for the ControlLogix platform, delivering exceptional accuracy and isolation in critical process control applications. With 8 individually isolated differential channels, it provides robust signal integrity for sensors, transmitters, and transducers in manufacturing, oil and gas, and power generation environments. The module features a wide input range selection and overvoltage protection, ensuring reliable data acquisition even in electrically noisy conditions. Its compact design fits seamlessly into standard 1756 chassis, offering easy installation and maintenance. For engineers demanding precise measurement and system uptime, the 1756-LSC8XIB8I is the trusted choice for demanding industrial automation tasks.

Parameter	Specification
Module Type	Analog Input Module
Model Number	1756-LSC8XIB8I
Channels	8 differential, individually isolated
Input Resolution	16-bit (15 bits plus sign)
Input Voltage Ranges	±10V, 0-10V, 0-5V, ±5V
Input Current Ranges	0-20mA, 4-20mA
Isolation Voltage	500V AC/DC (channel-to-channel and channel-to-backplane)
Update Rate	2 ms per channel (typical)
Accuracy	±0.05% of full scale at 25°C (typical)
Common Mode Rejection	> 120 dB at 50/60 Hz
Input Impedance	Voltage: > 1 MΩ; Current: 250 Ω (with external resistor)
Overvoltage Protection	±30V continuous
Power Consumption	2.5 W (typical from backplane)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% non-condensing
Vibration Resistance	5 g at 10-500 Hz (operating)
Shock Resistance	30 g peak acceleration (11 ms half-sine)
LED Indicators	Power, Status, Channel Active, Fault (per channel)
Connector Type	Removable terminal block (RTB) with screw clamps
Backplane Current	200 mA at 5V DC; 50 mA at 24V DC
Weight	Approx. 0.45 kg (1.0 lb)
Certifications	CE, cULus, ATEX (Zone 2), IECEx (Zone 2)
Compatible Chassis	1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17, 1756-A20
Warranty	Standard 2 years (extended available)
