Allen-Bradley 1756-ON8 AC Output Module

Series#: AllenBradley

Product Details

1756-ON8 Allen-Bradley ControlLogix 8-Point DC Sinking/Sourcing Input Module – high-density digital I/O for demanding automation.
8 isolated input channels, 10-30V DC sinking or sourcing, with high-speed response up to 1 kHz.
Hot-swappable in ControlLogix chassis, reducing downtime during maintenance.
Built-in diagnostics with LED status indicators for each point, simplifying troubleshooting.
Wide operating temperature range (-20°C to +60°C) for harsh industrial environments.
Compatible with 1756-series backplanes and standard ControlLogix firmware.
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The 1756-ON8 from Allen-Bradley is a high-performance digital input module designed for the ControlLogix platform. It provides eight isolated input channels, each configurable for either sinking or sourcing DC signals, making it ideal for monitoring discrete sensors, limit switches, and pushbuttons in manufacturing lines. With robust isolation and fast response times, this module ensures reliable data acquisition even in electrically noisy environments. Its hot-swappable design allows for module replacement without powering down the chassis, maximizing system uptime. Backed by Rockwell Automation's rigorous quality standards, the 1756-ON8 is a trusted solution for both new installations and legacy system upgrades.

Specification	Details
Product Type	Digital Input Module (DC)
Part Number	1756-ON8
Number of Input Points	8
Input Voltage Range	10-30V DC (sinking or sourcing)
Input Current (per point)	6 mA typical at 24V DC
Input On-State Voltage	≥ 10V DC
Input Off-State Voltage	≤ 5V DC
Input On-State Current	≥ 2.5 mA
Input Off-State Current	≤ 1.0 mA
Response Time (On to Off)	1 ms typical
Response Time (Off to On)	1 ms typical
Isolation Voltage	1500V DC between input and backplane
Backplane Current (5V)	120 mA
Backplane Current (24V)	0 mA (module powered via backplane)
Power Dissipation	1.5 W typical
Thermal Dissipation	5.1 BTU/hr typical
Indicators	8 green/red LED status per channel, plus module status LED
Module Type	Standard (non-isolated per point, but group isolated)
Wiring Style	Removable terminal block (RTB) with screw clamps
Operating Temperature	-20°C to +60°C (-4°F to +140°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Relative Humidity	5% to 95% non-condensing
Vibration Resistance	5 g Standard Models 10-500 Hz (operating)
Shock Resistance	30 g (operating)
Certifications	cULus, CE, ATEX (Zone 2), IECEx (Zone 2)
Weight	0.25 kg (0.55 lbs)
Dimensions (H x W x D)	144 x 35 x 100 mm (5.67 x 1.38 x 3.94 in)
Compatibility	ControlLogix 1756 chassis (all revisions)
Firmware Compatibility	Revision 1.0 or higher (requires RSLogix 5000 v16+)
