Siemens 6ES5482-7LF31 SIMATIC S5

Series#: Siemens

Product Details

6ES5482-7LF31 – High-performance SIEMENS SIMATIC S5 analog input module for industrial process control.
8-channel analog input interface, designed for 0 to 10 V and 4 to 20 mA signals, ensuring precise data acquisition.
Robust isolation technology for noise immunity in harsh factory environments, minimizing signal interference.
Easy integration into existing S5 racks with standard backplane connectors and STEP 5 configuration support.
Extended temperature range (-25°C to +60°C) for reliable operation in demanding industrial settings.
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The 6ES5482-7LF31 is a field-proven analog input module from the SIEMENS SIMATIC S5 series, engineered for precise measurement and monitoring in automation systems. This module features 8 differential analog inputs with high resolution and galvanic isolation, making it ideal for connecting sensors, transducers, and process transmitters in applications like chemical processing, water treatment, and manufacturing. Its rugged construction ensures long-term reliability even in electrically noisy environments, while the plug-in terminal design simplifies wiring and maintenance. As a legacy component, the 6ES5482-7LF31 remains critical for maintaining and upgrading existing S5 installations without complete system overhaul.

Parameter	Specification
Product Type	Analog Input Module
Model Number	6ES5482-7LF31
Series	SIEMENS SIMATIC S5
Number of Inputs	8 (differential)
Input Signal Range	0 to 10 V, 4 to 20 mA (selectable per channel)
Resolution	12 bits (including sign)
Conversion Time	Approx. 2 ms per channel
Isolation	Galvanic isolation between channels and backplane (500 VAC)
Supply Voltage	24 V DC (via backplane bus)
Current Consumption	Typical 100 mA from 24 V DC
Operating Temperature	-25°C to +60°C
Storage Temperature	-40°C to +85°C
Relative Humidity	5% to 95% (non-condensing)
Dimensions (W x H x D)	Approx. 40 mm x 125 mm x 120 mm (single-width module)
Weight	Approx. 200 g
Mounting	Plug-in into S5 rack (e.g., 6ES5 900-xxx series)
Terminal Type	Front connector (screw-type, 20-pin)
LED Indicators	Power (green), Channel status (per channel, yellow)
Protocol / Bus	Proprietary S5 backplane bus
Configuration Software	STEP 5 (COM 525 or similar)
Protection Class	IP20 (enclosed module)
Standards Compliance	IEC 61131-2, EN 55022, EN 61000-6-2
Application	Process control, monitoring, data acquisition
