Siemens 6ES5482-7LA11 SIMATIC S5

Series#: Siemens

Product Details

6ES5482-7LA11 – High-performance SIMATIC S5 interface module for industrial automation systems.
Designed for reliable data exchange in Siemens S5-115U, S5-135U, and S5-155U programmable logic controllers.
Supports RS-485 communication protocol for robust and noise-immune serial links.
Ideal for remote I/O expansion and distributed control in harsh manufacturing environments.
Direct drop-in replacement for existing S5 modules, ensuring minimal downtime during upgrades.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Siemens SIMATIC S5 interface module 6ES5482-7LA11 is a critical component for legacy industrial control systems requiring stable and deterministic communication. Engineered for the S5-115U, S5-135U, and S5-155U platforms, this module facilitates efficient data transfer between the central processing unit and remote I/O stations via RS-485. Its rugged design withstands temperatures from 0°C to 60°C and high electromagnetic interference, making it suitable for factory floors, process plants, and material handling systems. With a transmission rate of up to 187.5 kbit/s, the 6ES5482-7LA11 ensures real-time control in multi-drop network topologies. Below is the detailed technical specification table for this module.

Parameter	Specification
Product Type	Interface Module for SIMATIC S5
Model Number	6ES5482-7LA11
Compatible PLC Systems	S5-115U, S5-135U, S5-155U
Communication Interface	RS-485 (2-wire, half-duplex)
Maximum Transmission Rate	187.5 kbit/s
Number of Channels	1 (serial)
Isolation	Galvanic isolation between interface and PLC backplane (500 VAC, 1 min)
Power Consumption	Typical 2.5 W from 5 V DC backplane supply
Operating Temperature	0°C to +60°C (32°F to 140°F)
Storage Temperature	-40°C to +70°C (-40°F to 158°F)
Relative Humidity	5% to 95% (non-condensing)
EMC Immunity	EN 50082-2, EN 61000-6-2 (industrial environment)
Protection Class	IP20 (with enclosure)
Connector Type	9-pin D-sub (male) for RS-485; 20-pin front connector for backplane
Maximum Cable Length	1200 meters (at 187.5 kbit/s)
Supported Protocols	PROFIBUS-DP (via S5 CP modules), S5-specific serial protocol
Diagnostics	LED indicators for power, data activity, and fault status
Weight	Approximately 0.25 kg
Dimensions (W x H x D)	40 mm x 125 mm x 115 mm (single-width module)
Certifications	CE, UL, CSA (for industrial control equipment)
Warranty	Standard 12 months from shipment, extendable
