The 6ES5470-8MC12 SIEMENS SIMATIC S5 analog input module is a critical component for legacy S5 automation systems, designed to convert analog signals from field devices into digital values for the PLC. This module features 8 differential inputs, each configurable for voltage or current measurement, with a resolution of 12 bits. Its galvanic isolation between channels and backplane bus provides superior noise immunity, making it suitable for demanding industrial applications like chemical processing, manufacturing, and energy management. The module operates within a wide temperature range of 0°C to 60°C and includes diagnostic LEDs for quick fault identification. Below are the detailed technical specifications:
| Parameter |
Specification |
| Product Type |
Analog Input Module |
| Model Number |
6ES5470-8MC12 |
| System Compatibility |
SIEMENS SIMATIC S5 (e.g., S5-115U, S5-135U, S5-155U) |
| Number of Inputs |
8 differential channels |
| Input Signal Ranges |
0 to 10V, 0 to 20mA, 4 to 20mA (selectable per channel) |
| Resolution |
12 bits (including sign bit) |
| Conversion Time |
Approx. 0.5 ms per channel (total cycle time ~4 ms for all channels) |
| Input Impedance |
Voltage mode: > 100 kΩ; Current mode: 250 Ω (burden) |
| Galvanic Isolation |
Between channels and backplane bus: 500 VAC (test voltage) |
| Power Supply |
5V DC from backplane bus (typical current consumption: 200 mA) |
| Diagnostics |
LED indicators for power, channel status, and fault (per channel) |
| Operating Temperature |
0°C to +60°C (storage: -40°C to +85°C) |
| Dimensions (W x H x D) |
Approx. 40 mm x 125 mm x 120 mm (standard S5 module form factor) |
| Weight |
Approx. 0.25 kg |
| Protection Class |
IP20 (for use in control cabinets) |
| Standards Compliance |
IEC 61131-2, EN 50081-2 (EMC), EN 61000-6-2 |
