Delta DVP-SX2 CPU Controller

Series#: Delta

Product Details

DELTA DVP-SX2 Series PLC Controller – Advanced Analog Slim PLC with integrated mixed I/O for precision automation.
Features 8 digital inputs (including 4 analog inputs) and 6 digital outputs (including 2 analog outputs) in a compact form factor.
Available in Relay (DVP20SX211R), Transistor (DVP20SX211T), and PNP Transistor (DVP20SX211S) output variants.
24 VDC power supply ensures reliable operation in industrial environments with low power consumption.
Ideal for applications requiring simultaneous analog and digital control, such as process monitoring, HVAC, and packaging systems.

Specification

The DELTA DVP-SX2 Series represents a pinnacle of integrated analog and digital control in a slim, space-saving PLC package. Designed for applications demanding precise analog signal processing alongside standard discrete I/O, the DVP20SX211R, DVP20SX211T, and DVP20SX211S models combine 8 digital inputs (with 4 channels configurable as analog inputs) and 6 digital outputs (with 2 channels configurable as analog outputs) in a single compact unit. This series eliminates the need for separate analog expansion modules in many mid-range tasks, streamlining panel design and reducing wiring complexity.

Specification	DVP20SX211R (Relay)	DVP20SX211T (Transistor NPN)	DVP20SX211S (Transistor PNP)
Power Supply	24 VDC	24 VDC	24 VDC
Digital Inputs	8 (4 AI integrated)	8 (4 AI integrated)	8 (4 AI integrated)
Digital Outputs	6 (2 AO integrated)	6 (2 AO integrated)	6 (2 AO integrated)
Output Type	Relay (2A/point)	NPN Transistor (0.5A/point)	PNP Transistor (0.5A/point)
Analog Input Resolution	12-bit (0-10V / 4-20mA)	12-bit (0-10V / 4-20mA)	12-bit (0-10V / 4-20mA)
Analog Output Resolution	12-bit (0-10V / 4-20mA)	12-bit (0-10V / 4-20mA)	12-bit (0-10V / 4-20mA)
Program Capacity	16K steps	16K steps	16K steps
Communication Ports	1 RS-232, 1 RS-485	1 RS-232, 1 RS-485	1 RS-232, 1 RS-485
Dimensions (WxHxD)	90 x 90 x 60 mm	90 x 90 x 60 mm	90 x 90 x 60 mm

Integrated Analog I/O: 4 analog inputs and 2 analog outputs (12-bit resolution) are built directly into the CPU, supporting voltage (0-10V) and current (4-20mA) signals for seamless process control.
High-Speed Processing: 16K-step program capacity with a basic instruction execution speed of 0.35 µs per step, enabling rapid logic and PID loop handling.
Flexible Output Options: Choose Relay (DVP20SX211R) for high-current switching, NPN Transistor (DVP20SX211T) for sinking loads, or PNP Transistor (DVP20SX211S) for sourcing loads.
Robust Communication: Dual serial ports (RS-232 and RS-485) support Modbus ASCII/RTU master/slave, allowing easy integration with HMIs, drives, and SCADA systems.
Compact & Durable Design: Slim 90mm width fits in tight panels, with IP20 protection and wide operating temperature range (-10°C to +55°C) for harsh industrial environments.
