Delta DVP-SE CPU Controller

Series#: Delta

Product Details

Model: Delta DVP-SE Series PLC Controller – Specifically the DVP26SE11R, DVP26SE11T, DVP12SE11R, and DVP12SE11T variants for network-type slim applications.
Integrated Ethernet Communication – Built-in network capability for seamless remote monitoring and control in distributed systems.
Compact Slim Design – Space-saving form factor ideal for panel mounting in tight industrial environments.
High-Speed Processing – Advanced CPU with fast scan times for real-time automation tasks.
Versatile I/O Configuration – Options from 8 to 14 inputs and 4 to 12 relay or transistor outputs.
Robust 24 VDC Power Supply – Reliable operation across a wide range of industrial applications.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Delta DVP-SE Series PLC Controller, including models like the DVP26SE11R and DVP12SE11T, represents a cutting-edge network-type slim programmable logic controller designed for modern automation systems. With its built-in Ethernet port, the DVP-SE series enables direct connection to industrial networks, facilitating data exchange, remote diagnostics, and SCADA integration. This series is engineered for applications requiring compact footprint, reliable performance, and seamless communication, making it ideal for machine control, packaging lines, and building automation. Each unit is 100% new and original, ensuring long-term durability and compatibility with Delta’s ecosystem.

Technical Specifications (DVP-SE Series)

Model	Power Supply	Output Method	Inputs	Outputs	Communication	Program Steps	Execution Speed
DVP26SE11R	24 VDC	Relay	14	12	Ethernet, RS-232, RS-485	16K steps	0.35 µs per basic instruction
DVP26SE11T	24 VDC	Transistor (NPN)	14	12	Ethernet, RS-232, RS-485	16K steps	0.35 µs per basic instruction
DVP12SE11R	24 VDC	Relay	8	4	Ethernet, RS-232, RS-485	16K steps	0.35 µs per basic instruction
DVP12SE11T	24 VDC	Transistor (NPN)	8	4	Ethernet, RS-232, RS-485	16K steps	0.35 µs per basic instruction

Key Technical Features

Built-in Ethernet Port: Supports Modbus TCP/IP, EtherNet/IP, and standard TCP/UDP protocols for easy network integration.
High-Speed Counters: Up to 4 channels of 200 kHz single-phase or 2-phase encoders for precise motion control.
Analog I/O Support (Optional): Expandable via DVP-SE series modules for voltage/current inputs and outputs.
PID Control: Built-in PID instructions with auto-tuning for temperature, pressure, and flow control loops.
Expandability: Supports up to 8 expansion modules for I/O, analog, or special function modules.
Real-Time Clock: Integrated RTC for time-stamped data logging and scheduled operations.
Program Security: Password protection and program lock to prevent unauthorized access.
Operating Temperature: -10°C to +55°C, suitable for harsh industrial environments.
