Rohde & Schwarz FSV30 Signal and Spectrum Analyzer

Series#: Rohde & Schwarz

Product Details

ROHDE & SCHWARZ FSV30 – High-performance signal and spectrum analyzer covering 10 Hz to 30 GHz for bench, production, and field use.
Up to 160 MHz analysis bandwidth for advanced digital modulation analysis on 5G, LTE, and WLAN signals.
200 M sample signal memory for capturing long sequences in I/Q analysis and transient events.
Comprehensive measurement suite: ACLR, SEM, spurious emissions, phase noise, noise figure, and CCDF.
Optional tracking generator up to 7 GHz for scalar network analysis (frequency response, gain, bandwidth).
Intuitive operation with hotkeys and rich marker functions including peak search, n dB down, and demodulation.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The ROHDE & SCHWARZ FSV30 is a versatile signal and spectrum analyzer engineered for demanding RF measurements from 10 Hz to 30 GHz, making it essential for R&D, production testing, and field diagnostics. Its wide 160 MHz analysis bandwidth supports modern digital modulation standards including 5G NR, LTE-Advanced, and IEEE 802.11ax, enabling accurate component and base station characterization. The instrument excels in spectrum emission mask (SEM) compliance, spurious emission scanning, and adjacent channel leakage ratio (ACLR) testing, while optional applications for EMI diagnostics, phase noise, noise figure, analog demodulation, and vector signal analysis extend its functionality. With a deep 200 M sample memory for I/Q data and a 7 GHz tracking generator option, the FSV30 delivers robust performance for both spectral and network analysis tasks.

Parameter	Specification
Frequency Range	10 Hz to 30 GHz (FSV30 model)
Analysis Bandwidth	Up to 160 MHz (standard)
Displayed Average Noise Level (DANL)	Typ. –160 dBm/Hz at 1 GHz (preamp on)
Phase Noise	Typ. –110 dBc/Hz at 10 kHz offset (1 GHz carrier)
Level Measurement Uncertainty	< 0.5 dB up to 3 GHz, < 0.7 dB up to 30 GHz
Resolution Bandwidth (RBW)	1 Hz to 10 MHz (standard), up to 80 MHz (optional)
Video Bandwidth (VBW)	1 Hz to 10 MHz
Signal Memory	200 M samples (I/Q data capture)
Tracking Generator Option	Available up to 7 GHz (R&S FSV-B9)
Digital Modulation Analysis	5G NR, LTE, WLAN 802.11a/b/g/n/ac/ax, Bluetooth, etc.
Measurement Functions	Channel power, ACLR, SEM, spurious emissions, CCDF, APD, phase noise, noise figure, analog demodulation
Marker Functions	Peak search, signal count, n dB down, noise marker, phase noise marker, demodulation
Connectivity	USB, LAN, GPIB (optional), HDMI, external trigger
Operating Temperature Range	0 °C to +50 °C
Weight	Approx. 16 kg (with handle)
Included Accessories	Power cord, quick start guide, calibration certificate
