The Siemens SIMATIC TP 177B PN/DP, model 6AV6642-0BA01-1AX1, is a robust 6-inch operator panel designed for demanding industrial environments. This spare part offers a high-resolution STN color display with 256 colors, providing clear visualization for process data and alarms. It supports multiple communication protocols including MPI, PROFIBUS DP via RS485/RS422, and Ethernet 10/100, enabling flexible integration into both legacy and modern automation networks. The panel features a USB interface for data transfer, a printer port for hard-copy reports, and an MMC slot for configuration backup. With a net weight of just 1.037 kg and compact dimensions (20.20 x 25.30 x 8.90 cm), it is easy to install in standard cutouts. This unit is configured using Siemens WinCC flexible 2005 software, ensuring compatibility with a wide range of Siemens controllers. As a genuine spare part, it is manufactured in Germany and complies with RoHS directives since 31.03.2008. Please note this product is in the cancellation phase (PLM PM410) and is available as a spare part only.
| Product Identification |
| Article Number |
6AV6642-0BA01-1AX1 |
| Product Description |
SIMATIC TP 177B 6" PN/DP STN, 256 color display, MPI/PROFIBUS DP, Ethernet 10/100, USB, printer interface, MMC slot, configurable with WinCC flexible 2005 |
| Product Family |
SIMATIC HMI |
| Product Lifecycle (PLM) |
PM410: Product cancellation (since 01.10.2021) |
| Country of Origin |
Germany |
| Display & Interface |
| Display Type |
STN, 256 colors |
| Display Size |
6 inches (diagonal) |
| Touch Screen |
Yes (analog resistive) |
| Resolution |
320 x 240 pixels |
| Communication Interfaces |
| PROFIBUS DP |
RS485/RS422 (MPI/PROFIBUS DP protocol) |
| Ethernet |
10/100 Mbit/s (RJ45) |
| USB |
1 x USB (type B, for data transfer) |
| Printer Interface |
1 x (Centronics compatible) |
| MMC Slot |
1 x (for MMC card) |
| Power & Environmental |
| Supply Voltage |
24 V DC (nominal) |
| Power Consumption |
Typ. 0.3 A at 24 V DC |
| Operating Temperature |
0 °C to +50 °C |
| Storage Temperature |
-20 °C to +60 °C |
| Relative Humidity |
10% to 90% (non-condensing) |
| Mechanical Data |
| Net Weight |
1.037 kg |
| Packaging Dimensions (L x W x H) |
20.20 x 25.30 x 8.90 cm |
| Packaging Quantity |
1 piece |
| Protection Class |
IP65 (front panel), IP20 (rear) |
| Compliance & Logistics |
| RoHS Compliance |
Since 31.03.2008 |
| Export Control |
ECCN: 9N9999 / AL: N |
| Commodity Code |
85371091 |
| EAN |
4.02552E+12 |
| UPC |
6.62643E+11 |
| SCIP Number |
45088f6a-a133-469d-8007-a683763e55d2 |
| WEEE Take-Back Obligation |
No |
| Estimated Dispatch Time |
On request (typically within 1-3 working days) |
| Software & Configuration |
| Configuration Software |
WinCC flexible 2005 |
| Firmware |
Pre-installed (version varies) |
| Supported Controllers |
Siemens S7-200, S7-300, S7-400, and other MPI/PROFIBUS devices |
