Delta VFD110C43A Inverter

Series#: Delta

Product Details

Delta Inverters C2000 Series 11kW VFD110C43A 380V – high-performance vector control drive for industrial automation.
Rated output: 11kW (15HP) at 380V three-phase input, ideal for pumps, fans, conveyors, and machine tools.
Advanced sensorless vector control (SLV) and closed-loop vector control (FOC) for precise torque and speed regulation.
Built-in PLC function, multi-pump control, and fieldbus communication options (Modbus, CANopen, Profibus).
Robust design with IP20 enclosure, built-in EMC filter, and overload capacity up to 150% for 60 seconds.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Delta Inverters C2000 Series VFD110C43A 380V is a compact yet powerful 11kW variable frequency drive engineered for demanding industrial applications. This model leverages Delta’s proprietary vector control algorithms to deliver exceptional motor performance, energy savings, and reliability. The VFD110C43A supports both induction and permanent magnet motors, making it a versatile choice for retrofitting existing systems or integrating into new automation lines. With built-in PID control, programmable digital and analog I/O, and support for multiple communication protocols, it simplifies system integration while reducing downtime. Whether controlling a conveyor belt, a centrifugal pump, or a high-speed spindle, the C2000 ensures smooth operation and precise process control.

Parameter	Specification
Model Number	VFD110C43A
Series	Delta C2000
Rated Power	11 kW (15 HP)
Input Voltage	3-Phase 380VAC, 50/60 Hz (±10%)
Output Voltage	3-Phase 0-380VAC (adjustable)
Rated Output Current	25 A
Control Method	V/F, Sensorless Vector (SLV), Closed-Loop Vector (FOC)
Frequency Range	0.00 – 599.00 Hz (resolution 0.01 Hz)
Overload Capacity	150% for 60 seconds; 200% for 3 seconds
Braking Torque	20% without braking unit; up to 125% with optional braking resistor
Digital Inputs	6 programmable NPN/PNP
Digital Outputs	3 programmable (2 relay + 1 open collector)
Analog Inputs	2 (0-10V / 4-20mA selectable)
Analog Outputs	2 (0-10V / 4-20mA selectable)
Built-in PLC	Yes, with ladder logic programming (max 500 steps)
Communication Protocols	Modbus RTU (standard), CANopen (optional), Profibus-DP (optional)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, phase loss, motor overload
Enclosure Rating	IP20
Ambient Temperature	-10°C to +50°C (derate above 40°C)
Dimensions (W x H x D)	Approx. 180 mm x 300 mm x 200 mm
Weight	Approx. 4.5 kg
Certifications	CE, UL, cUL, RoHS
