The 1794-IF2XOF2I Allen-Bradley FLEX I/O analog module is a critical component for advanced process control, offering a dual-function design that merges two differential analog input channels with two analog output channels. Engineered for reliability in demanding industrial environments, this module supports standard voltage and current ranges, ensuring compatibility with a wide array of sensors and actuators. Its compact form factor allows for efficient use of panel space in distributed control systems, while the galvanic isolation between channels minimizes signal interference. Whether deployed in oil and gas, manufacturing, or water treatment facilities, the 1794-IF2XOF2I delivers consistent performance with high resolution and fast update rates, making it an ideal choice for real-time monitoring and closed-loop control applications.
| Parameter |
Specification |
| Product Type |
FLEX I/O Analog Combination Module |
| Model Number |
1794-IF2XOF2I |
| Input Channels |
2 differential analog inputs |
| Output Channels |
2 analog outputs |
| Input Ranges |
0-10V, 0-20mA, 4-20mA (software selectable per channel) |
| Output Ranges |
0-10V, 0-20mA, 4-20mA (software selectable per channel) |
| Input Resolution |
16-bit (including sign) |
| Output Resolution |
16-bit (including sign) |
| Update Rate |
10 ms per module (all channels) |
| Accuracy |
±0.1% of full scale at 25°C (typical) |
| Isolation |
500V DC continuous between channels and backplane |
| Power Supply Requirement |
5V DC at 150 mA (from backplane) |
| Operating Temperature |
-20°C to +60°C (-4°F to +140°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
| Relative Humidity |
5% to 95% non-condensing |
| Dimensions (H x W x D) |
120 mm x 45 mm x 75 mm (4.72 in x 1.77 in x 2.95 in) |
| Weight |
Approximately 0.15 kg (0.33 lbs) |
| Compatibility |
Allen-Bradley FLEX I/O system (1794 series) |
| Certifications |
CE, UL, C-UL, ATEX (for hazardous locations) |
