Allen-Bradley 1794-OA16 Flex I/O Output Module

Series#: AllenBradley

Product Details

1794-OA16 Allen-Bradley FLEX I/O Output Module – designed for reliable industrial automation control.
Features 16 isolated AC output channels for driving loads up to 120/240V AC.
Compact, modular design with hot-swappable terminal base for easy installation and maintenance.
High-density output configuration saves panel space in distributed I/O systems.
Built-in optical isolation and surge protection for robust performance in harsh environments.
Compatible with all Allen-Bradley FLEX I/O communication adapters and controllers.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The Allen-Bradley 1794-OA16 is a high-performance FLEX I/O AC output module engineered for demanding industrial environments. This 16-point discrete output module provides isolated switching for AC loads up to 240V AC, making it ideal for controlling motors, solenoids, relays, and other field devices in manufacturing and process automation. The 1794-OA16 utilizes rugged solid-state triac outputs with built-in surge suppression, ensuring long-term reliability in applications with frequent switching cycles. Each output channel is individually fused and optically isolated from the backplane, protecting the control system from transient voltages. Designed for the FLEX I/O platform, this module snaps onto a terminal base unit (e.g., 1794-TB3 or 1794-TB3S) for quick wiring and removal without disturbing field wiring. It supports both local and remote I/O configurations via ControlNet, DeviceNet, or EtherNet/IP adapters, offering flexibility for distributed control architectures. The 1794-OA16 is certified for global use with CE, UL, and CSA approvals, and operates reliably in temperatures from -20°C to +55°C.

Specification	Details
Product Type	AC Output Module
Series	FLEX I/O
Part Number	1794-OA16
Outputs	16 discrete, isolated
Output Type	Triac (solid-state)
Output Voltage Range	85-265V AC (47-63 Hz)
Output Current per Point	0.5 A continuous (resistive load)
Total Output Current per Module	8 A max (all points on)
Inrush Current	5 A for 10 ms
Off-State Leakage Current	< 2 mA
Isolation Voltage	1500V AC (channel-to-backplane)
Surge Protection	Integrated MOV and RC snubber
Fusing	Individual channel fuses (user-replaceable)
Terminal Base Compatibility	1794-TB3, 1794-TB3S, 1794-TB3K
Communication Adapters	1794-ACN, 1794-ADN, 1794-AENT, etc.
Power Consumption	2.5 W (max) from backplane
Operating Temperature	-20°C to +55°C
Storage Temperature	-40°C to +85°C
Relative Humidity	5% to 95% non-condensing
Vibration Resistance	2 g Standard Models 10-500 Hz
Shock Resistance	15 g (11 ms)
Housing Material	Polycarbonate, UL 94V-0 rated
Dimensions (H x W x D)	94 x 46 x 75 mm (approx.)
Weight	Approximately 0.12 kg
Certifications	CE, UL, CSA, RoHS
Wiring	Removable terminal block, 14-22 AWG
Protection Class	IP20 (installed in enclosure)
