The Siemens LOGO! 230 RC, specifically the 6ED1052-1FB00-0BA6, is a compact logic module engineered for reliable control in AC environments. This unit integrates an onboard power supply for 115V/230V AC, 8 digital inputs, and 4 relay outputs rated for high-current loads. Its built alphanumeric display and keypad allow for intuitive ladder-logic programming without a PC, while the modular design supports expansion via Siemens LOGO! modules for analog signals, additional I/O, or communications. The 6ED1052-1FB00-0BA6 is the go-to solution for building automation, lighting control, and small machine applications where simplicity and robustness are paramount.
| Specification |
Details |
| Model Number |
6ED1052-1FB00-0BA6 |
| Product Family |
Siemens LOGO! 230 RC |
| Power Supply Voltage |
115V AC / 230V AC (auto-sensing) |
| Power Supply Type |
Integrated, AC only |
| Digital Inputs |
8 (DI 1 to DI 8) |
| Digital Outputs |
4 relay outputs (DO 1 to DO 4) |
| Output Type |
Relay (normally open) |
| Max. Output Current (per relay) |
10 A (resistive load), 2 A (inductive load) |
| Memory Blocks |
200 |
| Display |
Backlit LCD, 6 lines x 20 characters |
| Programming Language |
Ladder Diagram (LD) / Function Block Diagram (FBD) |
| Programming Software |
LOGO! Soft Comfort V8.3 or higher |
| Expandability |
Up to 8 expansion modules (e.g., DM8, AM2, CM EIA-485) |
| Real-Time Clock |
Integrated (with backup capacitor) |
| Protection Class |
IP20 |
| Operating Temperature |
0°C to +55°C |
| Dimensions (W x H x D) |
72 mm x 90 mm x 55 mm |
| Weight |
Approx. 190 g |
| Mounting |
DIN rail (35 mm) |
| Communication Interface |
LOGO! bus (for expansion modules) |
| Certifications |
CE, cULus, RCM, EAC |
