Siemens 6ES7315-1AF03-0AB0 CPU 315

Series#: Siemens

Product Details

Siemens SIMATIC S7-300 CPU 315, exact order number 6ES7315-1AF03-0AB0.
48 KB integrated work memory for the user program and data.
Integrated MPI port for programming and communication; no integrated PROFIBUS DP master on this CPU 315 variant.
24 V DC supply, permissible 20.4–28.8 V DC.
Expansion of FEPROM load memory with a compatible memory card, up to 4 MB.
Typical bit processing time 0.3 µs and word processing time 1 µs.
Check the installed CPU label, card type, bus connector and STEP 7 project before replacement.

WhatsApp Inquiry

Specification

Datasheet (PDF)

Overview

This earlier S7-300 CPU 315 variant provides 48 KB work memory and an MPI programming interface. Its load-memory arrangement uses the corresponding memory-card generation, so it should not be confused with newer MMC-based CPU 315 variants.

Technical specifications

Specification	Value
Product family	SIMATIC S7-300
CPU / order number	CPU 315 / 6ES7315-1AF03-0AB0
Rated supply	24 V DC
Permissible supply	20.4–28.8 V DC
Integrated work memory	48 KB
Load memory type	FEPROM memory-card expansion
Maximum memory-card capacity	4 MB
Integrated interface	MPI
Integrated PROFIBUS DP master	No
Typical bit operation	0.3 µs
Typical word operation	1 µs
S7 counters	Up to 64
S7 timers	Up to 128
Dimensions	80 × 125 × 130 mm
Approximate weight	530 g

Integration and replacement notes

The suffix 1AF03 identifies this exact hardware generation. Compare the CPU and memory card with the machine documentation before swapping: a CPU 315-2 DP adds a second network interface, while later S7-300 CPUs can use a different load-memory format.
