The SIEMENS SIMATIC S7-200 CPU 224XP PLC (order number 6ES7214-2BD23-0XB0) represents the pinnacle of the S7-200 series, offering a perfect balance between digital and analog I/O in a single, compact unit. Engineered for mid-range automation tasks, this AC-powered controller integrates 14 DC inputs, 10 relay outputs, 2 analog inputs, and 1 analog output, eliminating the need for additional expansion modules in many applications. Its dual RS-485 interfaces enable seamless communication via PPI or user-defined protocols, while the 12/16 KB program memory and 10 KB data memory provide ample space for complex logic. Designed for industrial resilience, the CPU 224XP operates reliably across a wide temperature range and withstands vibration and dust typical of factory floors. Programming is streamlined through the MicroWin software suite, allowing ladder logic, function block, and statement list development. Whether used standalone or as part of a larger S7-200 network, this PLC delivers exceptional performance, scalability, and cost-efficiency.
| Specification |
Details |
| Product Type |
Programmable Logic Controller (PLC) – Compact Unit |
| Model |
6ES7214-2BD23-0XB0 (CPU 224XP) |
| Power Supply |
AC Models: 120–230 V AC, 50/60 Hz |
| Digital Inputs |
14 DI, DC (sink/source), 24 V DC |
| Digital Outputs |
10 DO, Relay (2 A per point, resistive load) |
| Analog Inputs |
2 AI, 0–10 V / 0–20 mA (8-bit resolution via potentiometer) |
| Analog Output |
1 AO, 0–10 V / 0–20 mA (8-bit resolution) |
| Program Memory |
12 KB (standard) / 16 KB (expansion) – RAM |
| Data Memory |
10 KB – RAM |
| Communication Ports |
2 x RS-485 (PPI, user-programmable, up to 187.5 kbps) |
| High-Speed Counters |
4 counters (single-phase: up to 30 kHz; two-phase: up to 20 kHz) |
| Pulse Outputs |
2 pulse train outputs (up to 20 kHz, open collector) |
| Expansion Capability |
Up to 7 expansion modules (digital, analog, or special function) |
| Programming Software |
MicroWin (STEP 7-Micro/WIN) – LAD, FBD, STL |
| Operating Temperature |
0°C to +55°C (storage: -40°C to +70°C) |
| Relative Humidity |
5% to 95% (non-condensing) |
| Protection Class |
IP20 (enclosure) |
| Dimensions (W x H x D) |
80 mm x 120 mm x 62 mm |
| Weight |
Approx. 390 g |
| Standards |
CE, UL, cUL, FM, RoHS compliant |
| Application |
Mid-range automation, process control, machine control, HVAC, packaging |
