The SIMATIC S7-200 S7-222 PLC CPU 222 AC RLY OUTPUT 6ES7212-1BB23-0XB0 represents a benchmark in compact micro-PLC design, purpose-built for cost-sensitive yet demanding automation applications. As a core member of the S7-200 family, this CPU 222 unit delivers a balanced mix of digital I/O, relay switching capability, and expandable fieldbus connectivity via PROFIBUS DP. Its AC-powered design simplifies installation in environments where DC supplies are unavailable, while the onboard relay outputs provide galvanic isolation and high current handling for direct actuator control. Whether deployed in standalone machinery, conveyor systems, or building automation nodes, this controller offers a proven path to reliable, scalable automation.
| Parameter |
Specification |
| Product Type |
SIMATIC S7-200 CPU 222 Compact Unit |
| Model Number |
6ES7212-1BB23-0XB0 |
| Power Supply |
AC 120/230 V, 50/60 Hz |
| Digital Inputs |
8 DI, 24 V DC, sink/source configurable |
| Digital Outputs |
6 DO, Relay, 2 A per channel, resistive load |
| Program Memory |
4 KB (user program) |
| Data Memory |
2 KB (retentive data) |
| Bit Execution Time |
0.37 µs per instruction |
| Communication Interface |
1x RS-485 (PROFIBUS DP expandable via EM 277) |
| Max. Expansion Modules |
2 (digital or analog) |
| High-Speed Counter |
4 channels, up to 30 kHz |
| Pulse Outputs |
2 channels, up to 20 kHz |
| Real-Time Clock |
Optional (via battery cartridge) |
| Operating Temperature |
0 °C to +55 °C |
| Storage Temperature |
-40 °C to +70 °C |
| Relative Humidity |
95% non-condensing |
| Protection Class |
IP20 (open type) |
| Dimensions (W x H x D) |
90 x 80 x 62 mm |
| Weight |
Approx. 270 g |
Technical Highlights: The CPU 222 AC model excels in applications requiring moderate I/O counts with relay isolation. Its PROFIBUS DP expansion capability allows integration into larger Siemens networks, while the onboard high-speed counters and pulse outputs support simple motion control tasks. The relay outputs are rated for 2A at 250 V AC or 30 V DC, making them suitable for switching small motors, valves, and indicator lights directly without external interface relays. All inputs are optically isolated and support 24 V DC sensors with configurable filtering for noise immunity. The unit is fully compatible with STEP 7-Micro/WIN programming software, offering ladder logic, function block diagram, and statement list editors.
