The SIMATIC S7-200 S7-222 PLC CPU 222 DC 24V DC Output | 6ES7212-1AB23-0XB0 is a compact, high-performance controller designed for demanding automation applications. As part of the renowned S7-200 family, this CPU offers a robust combination of digital I/O, ample program memory, and PROFIBUS DP expandability, making it a versatile solution for standalone or networked systems. Its DC power supply ensures stable operation in industrial settings, while the transistor outputs provide fast switching for precise control.
Technical Specifications
| Parameter |
Value |
| Product Type |
S7-222 CPU 222 Compact Unit |
| Order No. |
6ES7212-1AB23-0XB0 |
| Power Supply |
24V DC |
| Digital Inputs |
8 DI DC (sink/source) |
| Digital Outputs |
6 DO DC (transistor) |
| Program Memory |
4 KB |
| Data Memory |
2 KB |
| Communication Interface |
PROFIBUS DP (expandable) |
| Operating Voltage Range |
20.4V to 28.8V DC |
| Output Current per Channel |
0.75 A (max) |
Key Technical Insights
- Compact Design: All-in-one unit integrates CPU, I/O, and power supply for space-saving installation.
- Memory Capacity: 4 KB program memory supports up to 2048 instructions, while 2 KB data memory handles up to 1024 data words.
- I/O Performance: 8 DC inputs with 24V logic and 6 DC transistor outputs rated at 0.75 A each, capable of driving inductive loads.
- Network Expansion: PROFIBUS DP interface allows connection to distributed I/O systems and higher-level controllers.
- Power Supply Reliability: 24V DC input with reverse polarity protection ensures stable operation in harsh environments.
- Programming Flexibility: Compatible with STEP 7-Micro/WIN software for ladder logic, FBD, and STL programming.
