The PANASONIC PLC FP-XH SERIES represents a significant advancement in programmable logic controllers, combining high-speed processing with extensive I/O flexibility. The specific models AFPXHC40R, AFPXHC40RD, AFPXHC60R, and AFPXHC60RD are engineered for demanding automation tasks, offering 40 or 60 I/O points respectively. The "R" suffix denotes relay output, while "RD" indicates relay output with a built-in power supply for analog or specialty modules. These controllers feature a powerful 32-bit RISC processor, ensuring scan times as low as 0.04 µs per basic instruction. With integrated high-speed counters and pulse outputs, they excel in applications like packaging, material handling, and conveyor systems. The modular design allows seamless integration with FP-XH series expansion units, making them ideal for scalable and future-proof automation solutions.
| Parameter |
Specification |
| Model Numbers |
AFPXHC40R, AFPXHC40RD, AFPXHC60R, AFPXHC60RD |
| I/O Points |
40 (24 Inputs / 16 Outputs) for AFPXHC40R/RD; 60 (32 Inputs / 28 Outputs) for AFPXHC60R/RD |
| Output Type |
Relay (R) – 2A/250V AC, 2A/30V DC; RD includes additional power supply for expansion |
| Program Memory |
32 k steps (standard), expandable to 64 k steps via memory cassette |
| Processing Speed |
0.04 µs per basic instruction (LD), 0.2 µs per applied instruction |
| High-Speed Counters |
Up to 8 channels, single-phase: 100 kHz; two-phase: 50 kHz |
| Pulse Output |
Up to 4 channels, 100 kHz (independent or trapezoidal control) |
| Communication Ports |
Ethernet (10/100 Mbps), RS-485 (Modbus RTU), USB 2.0 (Type B) |
| Power Supply |
24 V DC (0.5 A for R models; 1.0 A for RD models) |
| Operating Temperature |
-10°C to +55°C (14°F to 131°F) |
| Storage Temperature |
-40°C to +70°C (-40°F to 158°F) |
| Humidity Range |
10% to 95% RH (non-condensing) |
| Dimensions (W x H x D) |
90 mm x 90 mm x 80 mm (AFPXHC40R/RD); 110 mm x 90 mm x 80 mm (AFPXHC60R/RD) |
| Weight |
Approx. 350 g (AFPXHC40R/RD); 450 g (AFPXHC60R/RD) |
- High-Speed Processing: 32-bit RISC CPU delivers scan times of 0.04 µs per basic instruction, ensuring real-time control in fast-paced automation.
- Built-in Motion Control: Supports up to 4 axes of pulse output (100 kHz) for stepper or servo motor control, plus 8 high-speed counter channels.
- Flexible I/O Expansion: Expandable up to 300 I/O points using FP-X series extension modules (e.g., analog, temperature, or additional digital I/O).
- Integrated Communication: Ethernet port enables remote monitoring and SCADA integration; RS-485 supports Modbus RTU for field device networking.
- Robust Power Supply: RD models include a built-in 24 V DC power supply (1.0 A) for powering sensors or analog modules directly.
- Reliable Relay Outputs: Rated for 2A/250V AC or 2A/30V DC, ideal for switching inductive loads like motors, solenoids, and contactors.
- Wide Environmental Tolerance: Operates from -10°C to +55°C with 95% humidity, suitable for factory floor and outdoor installations.
