Omron CP1W Series I/O Connecting Cable CP1W-SRT2

Series#: Omron

Product Details

OMRON CP1W-SRT2 PLC I/O Connecting Cable – Precision-engineered for seamless integration with OMRON CP1 series programmable logic controllers.
Designed for reliable signal transmission between I/O modules and field devices, minimizing noise and voltage drop.
Plug-and-play connectivity with robust connectors ensuring secure locking and vibration resistance in industrial environments.
Flexible, high-flex life cable jacket rated for continuous flexing applications in automation cells and control cabinets.
Compliant with international standards (CE, UL) for safe operation in harsh factory conditions.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The OMRON CP1W-SRT2 is a dedicated I/O connecting cable specifically engineered for the CP1 series of programmable logic controllers, providing a robust and shielded connection between expansion I/O units and the CPU. This cable ensures high-fidelity signal integrity over extended distances, critical for distributed I/O architectures in modern industrial automation systems. With its durable construction and precise pin-out configuration, the CP1W-SRT2 minimizes installation time and eliminates wiring errors, making it an essential component for scalable control solutions.

Parameter	Specification
Product Type	I/O Connecting Cable for OMRON CP1 Series
Model Number	CP1W-SRT2
Cable Length	2 meters (standard)
Connector Type	Male-to-Female, 20-pin (on CPU side) / 20-pin (on I/O unit side)
Wire Gauge	26 AWG (stranded copper)
Shielding	Overall foil + braid shield for EMI/RFI protection
Operating Temperature	-20°C to +60°C
Rated Voltage	24 VDC (max)
Current Rating	1 A per pin (total cable capacity 3 A)
Insulation Resistance	≥ 100 MΩ at 500 VDC
Dielectric Strength	500 VAC for 1 minute
Bending Radius (static)	≥ 5 x cable diameter
Bending Radius (dynamic)	≥ 10 x cable diameter
Flammability Rating	VW-1 (UL 1581)
Compliance	CE, UL, RoHS

Connector Locking Mechanism: Equipped with screw-lock or snap-lock (depending on revision) to prevent accidental disconnection under vibration.
Signal Integrity: Twisted-pair construction for critical I/O signals reduces crosstalk and ensures accurate data transmission.
Environmental Resistance: Cable jacket made of PVC or PUR (check variant) with oil and moisture resistance for industrial washdown areas.
Compatibility: Fully compatible with CP1W-20EDT, CP1W-40EDT, and all CP1 series expansion I/O units.
Installation: Pre-terminated with molded connectors; no field wiring or crimping required – reduces downtime.
Color Coding: Standard gray jacket with black connector bodies for easy identification in crowded cabinets.
Packaging: Supplied in anti-static bag with individual part number label for traceability.
