Mitsubishi FX3UC-96MT/D PLC Controller Module

Series#: Mitsubishi

Product Details

Mitsubishi FX3UC-96MT/D – High-performance PLC controller module with 96 I/O points for compact automation systems.
Supports up to 7,680 total auxiliary relays, 4,096 state relays, and 512 timers for complex logic control.
Equipped with 235 counters (16-bit and 32-bit) and high-speed counter inputs up to 100 kHz (1-phase) and 50 kHz (2-phase).
Offers 8,000 data registers and 32,768 extension registers for extensive data handling and memory expansion.
Ideal for FX3U/FX3UC series platforms, ensuring seamless integration and reliable performance in demanding industrial environments.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Mitsubishi FX3UC-96MT/D is a state-of-the-art PLC controller module designed for high-speed, multi-axis control in compact form factors. As part of the FX3UC series, it delivers exceptional processing power and memory capacity, making it suitable for advanced automation tasks such as motion control, data acquisition, and process management. With a robust set of relays, timers, counters, and registers, this module ensures precise sequencing and flexible logic implementation. Its 96-point I/O configuration, combined with high-speed counter capabilities, supports demanding applications like packaging, material handling, and machine tool automation. Built for durability and longevity, the FX3UC-96MT/D guarantees reliable operation in harsh industrial environments.

Parameter	Specification (FX3UC-96MT/D)
Auxiliary Relays	7,680 total: 500 general (M0–M499), 524 optional latched (M500–M1023), 6,656 latched (M1024–M7679)
State Relays	4,096 total: 1,000 optional latched (S0–S999), 3,096 latched (S1000–S4095)
Timers	512 total: 206 x 100 ms (T0–T191, T192–T199, T250–T255), 46 x 10 ms (T200–T245), 260 x 1 ms (T246–T249, T256–T511)
Counters	235 total (16-bit and 32-bit): 120 general (C0–C99, C200–C219), 115 latched (C100–C199, C220–C234)
High-Speed Counter Speed	1-phase: 8 points max at 100 kHz / 6 points at 10 kHz / 2 points; 2-phase: 2 points max at 50 kHz / 2 points
Data Registers	8,000 total: 200 general (D0–D199), 312 optional latched (D200–D511), 7,488 latched (D512–D7999)
Extension Registers	32,768 (R0–R32767)
Extension File Registers	32,768 (ER0–R32767) optional memory

High-Speed Processing: Supports up to 100 kHz single-phase and 50 kHz two-phase high-speed counters for precise motion and event capture.
Memory Expansion: 32,768 extension registers and file registers allow for extensive data logging and recipe storage.
Reliability: Latched relays and registers ensure critical data retention during power cycles, enhancing system stability.
Scalability: Compatible with FX3U/FX3UC series expansion modules for additional I/O and communication capabilities.
Industrial Grade: Designed for harsh environments with wide operating temperature range and robust construction.
