| Parameter |
Specification |
| Model |
PWS6A00T-N (HITECH Industrial HMI / Touchscreen) |
| Display Type |
10.4-inch TFT LCD with resistive touchscreen |
| Resolution |
800 × 480 pixels (WVGA) |
| Display Colors |
256 colors (standard palette) |
| Backlight |
CCFL (replaceable) – typical life 30,000 hours at 25°C |
| Touch Technology |
Resistive (analog, 4-wire) – durable for industrial use |
| Processor |
32-bit RISC CPU, 200 MHz |
| Memory |
On-board Flash & SRAM (for application storage and runtime) |
| Ethernet |
1 × 10/100Base-TX, RJ-45 (Ethernet/IP protocol) |
| Serial Ports |
1 × RS-232 (9-pin D-sub) + 1 × RS-485 (terminal block); supports PLC protocols (Mitsubishi, Siemens, Omron, etc.) |
| USB Ports |
1 × USB 1.1 Host (Type-A) for data transfer and firmware update |
| Power Supply |
24 VDC ±10% (standard industrial power) |
| Power Consumption |
Approx. 15 W (max) |
| Protection Rating |
IP65 (front panel, when properly installed) |
| Operating Temperature |
0°C to +50°C |
| Storage Temperature |
-20°C to +60°C |
| Humidity |
10% to 90% RH (non-condensing) |
| Vibration Resistance |
IEC 60068-2-6 compliant (5–9 Hz, 3.5 mm; 9–150 Hz, 1.0 g) |
| Shock Resistance |
IEC 60068-2-27 compliant (15 g, 11 ms) |
| EMC Compliance |
EN 55011, EN 61000-6-2, EN 61000-6-4 (industrial immunity & emission) |
| Safety Standards |
EN 60950-1 (Low Voltage Directive) |
| Enclosure Material |
Polycarbonate front bezel, metal rear chassis |
| Mounting |
Panel cut-out (standard 10.4-inch HMI form factor) |
| Weight |
Approx. 1.8 kg (3.97 lbs) |
| Dimensions (W×H×D) |
316 × 238 × 55 mm (12.44 × 9.37 × 2.17 inches) |
| Software Compatibility |
ADP (HITECH programming software) for screen design and protocol configuration |
| Supported PLC Protocols |
Mitsubishi FX/A series, Siemens S7-200/300, Omron Host Link, Modbus RTU, and more |
