Omron Inverter Communication Unit 3G3AX-MX2-ECT

Series#: Omron

Product Details

Omron Inverter MX2-Series EtherCAT Communication Unit 3G3AX-MX2-ECT – high-speed fieldbus interface for precision motion control.
Seamless integration with Omron MX2 inverters for real-time EtherCAT synchronization.
Supports CiA 402 drive profile with velocity mode and fixed PDO mapping.
Rugged IP20 open-type design, operates from -10°C to +50°C.
Fast delivery from stock – no lead time delays.
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

Engineered for demanding automation networks, the Omron Inverter MX2-Series EtherCAT Communication Unit 3G3AX-MX2-ECT provides a dedicated, high-reliability link between your MX2 drive and an EtherCAT master. This unit leverages the IEC 61158 Type12 standard and 100BASE-TX physical layer to achieve deterministic cycle times, making it ideal for packaging, material handling, and synchronized multi-axis applications. Its plug-and-play design ensures minimal commissioning effort, while the robust environmental specifications guarantee consistent performance in industrial settings.

Parameter	Specification
Power Supply	Supplied from the inverter
Protective Structure	Open type (IP20)
Ambient Operating Temperature	-10 to +50°C
Ambient Storage Temperature	-20 to +65°C
Ambient Operating Humidity	20% to 90% RH (non-condensing)
Vibration Resistance	5.9 m/s² (0.6 G), 10 to 55 Hz
Application Environment	Max altitude 1,000 m; indoors, free of corrosive gases and dust
Communications Standard	IEC 61158 Type12, IEC 61800-7 CiA 402 drive profile
Physical Layer	100BASE-TX (IEEE802.3)
Connector	RJ45 × 2 (shielded type); ECAT IN (EtherCAT input), ECAT OUT (EtherCAT output)
Communications Media	Category 5 or higher (double, aluminum tape and braided shielding recommended)
Communications Distance	Distance between nodes: 100 m max.
Process Data	Fixed PDO mapping
Mailbox (CoE)	Emergency messages, SDO, SDO responses, and information
Distributed Clock	FreeRun mode (asynchronous)
LED Display	L/A IN (Link/Activity IN) ×1, L/A OUT (Link/Activity OUT) ×1, RUN ×1, ERR ×1
CiA402 Drive Profile	Velocity mode

Network Synchronization: Operates in FreeRun mode for asynchronous distributed clock, ensuring flexible timing in multi-drive topologies.
Data Exchange: Fixed PDO mapping simplifies configuration; CoE mailbox supports SDO services for parameter access and diagnostics.
Diagnostic Visibility: Four dedicated LEDs (L/A IN, L/A OUT, RUN, ERR) provide instant status feedback for link activity, operational state, and error conditions.
Installation Requirements: Requires Category 5e or higher shielded cabling with double shielding (aluminum tape + braid) to maintain signal integrity over 100 m node-to-node distances.
