| Parameter |
Specification |
| Product Series |
Panasonic MINAS A4 |
| Rated Output Power |
2KW (for MEDDT7364, MEDDT7364003, MEDDT7364053, 052 models) |
| Main Circuit Power (100V models) |
Single phase, 100–115V +10% 50/60Hz –15% |
| Control Circuit Power (100V models) |
Single phase, 100–115V +10% 50/60Hz –15% |
| Main Circuit Power (200V A & B-frame) |
Single phase, 200–240V +10% 50/60Hz –15% |
| Main Circuit Power (200V C & D-frame) |
Single/3-phase, 200–240V +10% 50/60Hz –15% |
| Main Circuit Power (200V E & F-frame) |
3-phase, 200–230V +10% 50/60Hz –15% |
| Operating Temperature |
0 to 55°C |
| Storage Temperature |
–20 to +80°C |
| Humidity (Operating & Storage) |
90% RH or less (non-condensing) |
| Altitude |
1000m or lower |
| Vibration Resistance |
5.88 m/s² or less, 10 to 60Hz (no continuous resonance) |
| Control Method |
IGBT PWM Sinusoidal wave drive |
| Encoder Feedback |
17-bit (131072 resolution) absolute/incremental; 2500 P/r (10000 resolution) incremental |
| External Scale Feedback |
Mitutoyo AT500 series (0.05mm res., 2 m/s max); Mitutoyo ST771 (0.5mm res., 2 m/s max) |
| Control Signal Inputs |
10 inputs: Servo-ON, Control mode switching, Gain/Torque limit switching, Alarm clear, plus mode-specific inputs |
| Control Signal Outputs |
6 outputs: Servo alarm, Servo ready, External brake release, Zero speed detection, Torque in-limit, plus mode-specific outputs |
| Analog Signal Inputs |
3 inputs: 1 x 16-bit A/D, 2 x 10-bit A/D |
| Analog Signal Outputs |
2 outputs for monitoring: Velocity monitor, Torque monitor (approx. 3V/rated torque) or deviation counter/full-closed deviation |
| Pulse Signal Inputs |
4 inputs (line driver or photo-coupler, selectable via parameter) |
| Pulse Signal Outputs |
4 outputs: Encoder pulses (A, B, Z-phase) or external scale pulses (EXA, EXB, EXZ-phase) via line driver; Z-phase/EXZ-phase via open collector |
| Communication Interface |
RS232 (1:1 host communication); RS485 (1:n up to 15 axes) |
| Front Panel |
5 keys (MODE, SET, UP, DOWN, SHIFT) + 6-digit LED display |
| Regeneration |
A & B-frame: external resistor only; C to F-frame: built-in regenerative resistor (external also supported) |
| Dynamic Brake |
Configurable action at Power-OFF, Servo-OFF, protective function activation, and over-travel inhibit |
| Control Modes |
7 modes: Position, Velocity, Torque, Position/Velocity, Position/Torque, Velocity/Torque, Full-closed |
