The SIMATIC TP1200 Comfort 12" HMI (6AV2124-0MC01-0AX0) is a cutting-edge operator panel engineered for demanding industrial applications, offering a superior 12.1-inch widescreen TFT display with 1280 x 800 pixel resolution and 16 million colors. This touch-based unit replaces the legacy MP 277 10" Touch, providing 22% more display area and enhanced processing power. It supports up to 4000 messages, 500 process pictures, and 2048 variables, making it ideal for complex HMI tasks. With dual PROFINET interfaces, PROFIBUS/MPI connectivity, and flexible USB/SD storage, it ensures robust communication and data handling in modern automation environments.
| Technical Data |
TP1200 Comfort |
| Display |
12.1-inch TFT widescreen, 16 million colors |
| Resolution |
1280 x 800 px |
| Control Elements |
Touch screen |
| User Memory |
12 MB |
| Interfaces |
2 x RJ45 Ethernet (PROFINET), 1 x RS485/422 (PROFIBUS/MPI), 2 x USB host, 1 x USB device, 2 x SD card slot |
| Degree of Protection |
IP65 / NEMA 4x (front when mounted), IP20 (rear) |
| Installation Cutout |
310 x 221 mm (W x H) |
| Front Panel |
330 x 241 mm (W x H) |
| Device Depth |
63 mm |
| Configuration Software |
WinCC Comfort (TIA Portal) or higher |
| Messages |
4000 |
| Message Classes |
32 |
| Process Pictures |
500 |
| Variables |
2048 |
| Vector Graphics |
Supported |
| Bar Graphics |
Supported |
| Curve Diagrams |
f(t), f(x) |
| Recipes |
300 |
| Archiving |
50 |
| Visual Basic Scripts |
100 |
| Article Number |
6AV2124-0MC01-0AX0 |
- Processor Performance: High-speed ARM-based CPU optimized for rapid screen transitions and data processing.
- Communication Flexibility: Integrated PROFINET IO controller/device capability for direct fieldbus connectivity.
- Data Logging: Supports CSV-based archiving and recipe management for production traceability.
- Multilingual Support: Onboard runtime for up to 32 languages, including Unicode character sets.
- Certifications: CE, UL, CSA, and cULus listed for global deployment.
- Operating Temperature: 0°C to 50°C (vertical installation), suitable for industrial environments.
