The KP900 and TP900 Comfort series, including the specific model 6AV2124-1JC01-0AX0, represents a significant leap in HMI technology, offering a 9-inch widescreen TFT display with 16 million colors for unparalleled clarity. As the direct successors to the MP 277 8-inch panels, these units provide 32% more screen real estate and enhanced resolution, making them ideal for complex process visualization and control. Whether you need the tactile feedback of the KP900's 28 mechanical keys and 26 illuminated function keys, or the intuitive touch interface of the TP900, both deliver high-end performance within the TIA Portal ecosystem. With 12 MB user memory, support for up to 500 process pictures, and 2048 variables, they are engineered for demanding applications in manufacturing, energy, and infrastructure. All units are 100% original and new, supplied with full traceability for seamless integration.
| Technical Data |
TP900 Comfort |
KP900 Comfort |
| Hardware |
- |
| Display |
9.0 inch TFT widescreen display, 16 Mio colors |
| Resolution |
800 x 480 px |
| Control elements |
Touch screen |
Membrane Keypad (28 keys), 26 function keys with LED |
| User memory |
12 MB |
| Interfaces |
2 x RJ 45 Ethernet for PROFINET
1 x RS 485/422 for PROFIBUS/MPI
2 x USB-host, 1 x USB-device
2 x SD card slot |
| Degree of protection |
IP 65, NEMA 4x (front if mounted) / IP 20 rear |
| Installation cutout |
250 x 166 mm (W x H) |
338 x 206 mm (W x H) |
| Front panel |
274 x 190 mm (W x H) |
362 x 230 mm (W x H) |
| Device depth |
63 mm |
63 mm |
| Software functions |
- |
| Configuration software |
WinCC Comfort (TIA Portal) or higher |
| Messages |
4000 |
| Message classes |
32 |
| Process pictures |
500 |
| Variables |
2048 |
| Vector graphics |
x |
| Bar graphics |
x |
| Curve diagrams |
f (t), f (x) |
| Recipes |
300 |
| Archiving |
50 |
| Visual Basic Scripts |
100 |
| Article No. |
6AV2124-0JC01-0AX0 |
6AV2124-1JC01-0AX0 |
- Display Performance: 9.0-inch TFT widescreen with 16 million colors and 800 x 480 pixel resolution for crisp graphics and text.
- User Memory & Scalability: 12 MB internal memory supports up to 500 process pictures and 2048 variables, enabling complex HMI applications.
- Connectivity Suite: Dual PROFINET (RJ45) for real-time Ethernet, RS 485/422 for PROFIBUS/MPI, plus USB host/device and dual SD slots for data logging and firmware updates.
- Environmental Resilience: IP65/NEMA 4X front panel protection ensures dust and water jet resistance; IP20 rear for safe installation in cabinets.
- Software Integration: Fully configurable with WinCC Comfort (TIA Portal) for seamless integration into Siemens automation landscapes.
- Advanced Functions: Supports 4000 messages, 32 message classes, vector/bar graphics, curve diagrams (f(t), f(x)), 300 recipes, 50 archives, and 100 VBS scripts for advanced automation logic.
