Omron 3G3MX2-A4015-V1 AC Drive

Series#: Omron

Product Details

Product Model: 3G3MX2-A4015-V1 – A high-performance OMRON general-purpose inverter for industrial motor control.
Rated for 400V class input, 1.5 kW output power, ideal for precise speed and torque regulation.
Built-in advanced vector control and auto-tuning for enhanced motor efficiency.
Compact design with easy-to-use keypad and RS-485 communication port for seamless integration.
Supports multiple protection features including overvoltage, overcurrent, and thermal overload.
Compliant with international standards (CE, UL) for reliable operation in harsh industrial environments.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The OMRON 3G3MX2-A4015-V1 is a state-of-the-art variable frequency drive engineered for demanding industrial automation tasks. This model, part of the MX2 series, delivers robust performance for AC motor control in applications such as conveyors, pumps, fans, and compressors. With its 400V AC input and 1.5 kW output capacity, it ensures smooth acceleration and deceleration, reducing mechanical stress. The drive incorporates sensorless vector control for high starting torque and precise speed regulation, even at low speeds. Built for reliability, it features a durable heat sink and conformal-coated PCBs to resist dust and moisture. The integrated EMC filter minimizes electromagnetic interference, while the RS-485 Modbus RTU interface allows easy connection to PLCs and SCADA systems. This unit is factory-tested and backed by OMRON’s strict quality control, making it a trusted choice for global OEMs and system integrators.

Parameter	Specification
Model Number	3G3MX2-A4015-V1
Manufacturer	OMRON
Input Voltage	3-Phase, 380-480 VAC, 50/60 Hz
Output Power	1.5 kW (2.0 HP)
Rated Output Current	4.0 A (at 400 VAC)
Control Method	V/f Control, Sensorless Vector Control, Open Loop Vector
Frequency Range	0.1 to 400 Hz
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Protection Features	Overvoltage, Overcurrent, Undervoltage, Overheat, Ground Fault, Motor Overload (I²t)
Communication Interface	RS-485 (Modbus RTU), Built-in Keypad
Analog Inputs	1 x 0-10V / 4-20 mA (configurable)
Analog Outputs	1 x 0-10V / 4-20 mA (configurable)
Digital Inputs	8 (NPN/PNP selectable, including multi-function)
Digital Outputs	2 (1 relay, 1 open collector)
Braking Method	Dynamic Braking (built-in transistor)
Ambient Temperature	-10°C to +50°C (derated above 40°C)
Ambient Humidity	5% to 95% RH (non-condensing)
Enclosure	IP20 (NEMA 1)
Weight	Approx. 1.2 kg (2.65 lbs)
Certifications	CE, UL, cUL, RoHS
Warranty	12 months from date of shipment
