The OMRON 3G3MX2-A2075-V2 is a robust and versatile AC drive designed for demanding industrial applications requiring reliable variable speed control. This model, part of the MX2 series, delivers 7.5 kW of output power from a 200-240 VAC three-phase supply, making it suitable for a wide range of motor-driven equipment. With its sensorless vector control and auto-tuning capability, the 3G3MX2-A2075-V2 ensures optimal motor performance, energy savings, and smooth operation even under variable loads. The drive includes comprehensive protection features such as overcurrent, overvoltage, and overtemperature safeguards, along with built-in communication interfaces for seamless integration into control systems. Below are the detailed specifications for this model.
| Parameter |
Specification |
| Product Model |
3G3MX2-A2075-V2 |
| Rated Output Power |
7.5 kW (10 HP) |
| Input Voltage |
3-Phase, 200-240 VAC ±10% |
| Input Frequency |
50/60 Hz ±5% |
| Output Voltage |
3-Phase, 0-240 VAC (proportional to input) |
| Output Frequency |
0.0 to 400.0 Hz (adjustable) |
| Rated Output Current |
33.0 A |
| Control Method |
V/f, Sensorless Vector Control, or V/f with PG |
| Overload Capacity |
150% for 60 seconds, 200% for 0.5 seconds |
| Protection Class |
IP20 (NEMA 1) |
| Dynamic Braking |
Built-in transistor (external resistor required) |
| Built-in EMC Filter |
Yes (Class A, for industrial environments) |
| Communication Interface |
RS-485 Modbus RTU (standard), optional fieldbus modules |
| Analog Inputs |
2 (0-10 VDC or 4-20 mA, selectable) |
| Analog Outputs |
1 (0-10 VDC or 4-20 mA) |
| Digital Inputs |
6 (NPN/PNP selectable) |
| Digital Outputs |
2 (relay or open collector) |
| Ambient Temperature |
-10 to +50°C (14 to 122°F) without derating |
| Ambient Humidity |
20% to 90% RH (non-condensing) |
| Altitude |
Up to 1000 m without derating |
| Weight |
Approx. 3.5 kg (7.7 lbs) |
| Dimensions (W x H x D) |
140 x 260 x 165 mm (5.5 x 10.2 x 6.5 in) |
| Certifications |
CE, UL, cUL, RoHS |
