The Omron 3G3MX2-A2001-V1 is a compact yet powerful general-purpose inverter designed for reliable speed and torque control in a wide range of industrial applications. This model, part of the MX2 series, delivers 0.75 kW (1 HP) output from a 200V AC three-phase supply, making it suitable for small to medium-duty motor drives. With advanced sensorless vector control, it ensures stable operation even under varying loads, while built-in PID and PLC functions reduce the need for external controllers. The 3G3MX2-A2001-V1 also features intuitive keypad programming, RS-485 Modbus communication, and robust protection against overcurrent, overvoltage, and overheating, ensuring long-term reliability in harsh environments.
| Parameter |
Specification |
| Model |
3G3MX2-A2001-V1 |
| Rated Output Power |
0.75 kW (1 HP) |
| Input Voltage |
3-Phase 200V AC (170–253V) |
| Input Frequency |
50/60 Hz ±5% |
| Output Voltage |
3-Phase, 0–200V AC (proportional to input) |
| Output Frequency Range |
0.1–400 Hz (adjustable) |
| Control Method |
Sensorless Vector Control (V/f with slip compensation) |
| Overload Capacity |
150% for 60 seconds, 200% for 3 seconds |
| Protection Features |
Overcurrent, Overvoltage, Undervoltage, Overheat, Phase Loss, Ground Fault |
| Communication |
RS-485 Modbus RTU (standard) |
| Built-in Functions |
PID Control, Simple PLC (16 steps), Auto-Tuning, Energy Saving, Braking Transistor |
| Analog Inputs |
1 x 0–10V / 4–20 mA (selectable) |
| Digital Inputs |
6 programmable (e.g., Start/Stop, Multi-Speed, Jog) |
| Relay Outputs |
1 x Form C (SPDT) – Fault / Run indication |
| Ambient Temperature |
-10°C to +50°C (derating above 40°C) |
| Enclosure Rating |
IP20 (open chassis type) |
| Dimensions (W x H x D) |
Approx. 108 mm x 140 mm x 130 mm |
| Weight |
Approx. 1.2 kg |
| Applicable Motor |
Standard 3-Phase Induction Motor, 0.75 kW / 200V |
| Compliance |
CE, UL, cUL, RoHS |
