Product Overview – PFXSTC6300TADDCE
The PFXSTC6300TADDCE is a compact, rugged 5.7-inch HMI and controller combo designed for demanding automation tasks. This model features a digital output source type configuration, making it ideal for driving loads directly without external pull-up resistors. With a vivid 262K color resistive touch screen, it provides intuitive operator interface capabilities while integrating powerful I/O functions. It supports seamless expansion via Modicon TM3 modules, enabling flexible system scaling in machine control, process automation, and packaging lines.
Technical Specifications – PFXSTC6300TADDCE
| Specification |
Details |
| Model Number |
PFXSTC6300TADDCE |
| Output Type |
Digital Output Source Type |
| Display Size |
5.7” (VGA) / 262K colors / Resistive film (analog) |
| Serial Interface |
RS-232C/422/485 (D-Sub 9 pin) x 1 |
| Ethernet Interface |
IEEE802.3i / IEEE802.3u, 10BASE-T / 100BASE-TX x 1 |
| USB Interface |
USB host type A x 1, USB device Micro B x 1 |
| Expansion Interfaces |
DIO interface x 1, Expansion module interface x 1 |
| Built-in I/O |
DIO: Inputs 16 / Outputs 16 |
| High-Speed Counter / Pulse Catch Input |
Single phase: 4-point / 2 phase: 1-point or 2-point |
| Pulse / PWM Output |
4-point |
| External I/O Expansion (Rear) |
Modicon TM3 Module: Max 2 units |
| External I/O Expansion (Extension) |
Modicon TM3 Module: Max 8 units (requires Transmitter TM3XTRA1 and Receiver TM3XREC1) |
| Certifications |
CE, UL, cULus, cULus Class 1 Division 2, RMC, KC, EAC, ATEX/IECEx, RoHS, WEEE |
| Details |
Full specifications available at official product page |
