The Mitsubishi HMI Touch screen GT1020-LBLW/LWLW is a rugged, entry-level operator terminal designed for compact machine control and monitoring. Featuring a 3.7-inch STN monochrome liquid crystal display with white/black polarity, this model delivers crisp 160×64 dot resolution in a horizontal format. Its LED backlight offers three user-selectable colors (white, red, pink) with an estimated 50,000-hour life at 25°C, eliminating the need for lamp replacement. The analog resistive touch panel supports up to 50 touch keys per screen, with a minimum key size of 2×2 dots and a mechanical life exceeding 1 million actuations. Built for industrial durability, the front section meets IP67-equivalent protection (JEM1030) in horizontal mounting. The unit includes 512 KB flash memory for project data, alarm history, recipes, and time-action settings, with 100,000 write cycles. Communication with a PC is via RS-232 (115,200 to 4,800 baud) through a MINI DIN 6-pin female connector for project upload/download, OS installation, and transparent functions. Weighing only 0.18 kg (excluding mounting fixtures), the GT1020-LBLW/LWLW is compatible with GT Designer2 Version2.58L or later and GT Designer3 Version1.01B or later software packages.
| Item |
Specifications |
| Display type |
STN monochrome (white/black) liquid crystal |
| Screen size |
3.7″ |
| Resolution |
160 × 64 dots (horizontal format) |
| Display size |
W86.4 × H34.5 mm (3.4 × 1.35 in) (horizontal format) |
| Display characters |
16-dot standard font: 20 characters × 4 lines (horizontal format) |
| Display color |
Monochrome (white/black) |
| Display angle |
Left/Right: 30°, Top: 20°, Bottom: 30° (horizontal format) |
| Contrast adjustment |
16-level adjustment |
| LCD intensity (white) |
300 cd/m² |
| Backlight life |
Approx. 50,000 h (to 1/5 intensity at 25°C ambient) |
| Backlight colors |
LED: white, red, pink (no replacement required); status control (colors, ON/BLINK/OFF) with configurable screensaver |
| Touch panel keys |
Maximum 50 keys/screen (analog resistive film) |
| Key size (minimum) |
2 × 2 dots per key |
| Simultaneous press |
Not supported (two-point press may activate switch between areas) |
| Touch panel life |
1 million times or more (0.98N max. operating force) |
| Memory (C drive) |
Flash memory (internal), 512 KB max. for project data, OS, alarm history, recipe, time-action settings |
| Memory write life |
100,000 times |
| PC communication |
RS-232 1ch; speeds 115,200/57,600/38,400/19,200/9,600/4,800 bps; connector: MINI DIN 6-pin female; for project upload/download, OS installation, transparent function |
| Buzzer output |
Single tone (LONG/SHORT/OFF adjustable) on touch key press |
| Environmental protection |
Equivalent to IP67 (JEM1030) front section (horizontal format) |
| External dimensions |
W113 × H74 × D27 mm (4.44 × 2.91 × 1.06 in) (horizontal format) |
| Panel cutting dimensions |
W105 × H66 mm (4.13 × 2.59 in) (horizontal format) |
| Weight |
0.18 kg (excluding mounting fixtures) |
| Compatible software |
GT Designer2 Version2.58L or later / GT Designer3 Version1.01B or later |
- Power Supply: The unit requires an external 24 VDC power source (not included) – typical for Mitsubishi GOT1000 series compact HMIs.
- Mounting: Designed for panel mount with IP67 front seal; use provided mounting fixtures for secure installation.
- Environmental Limits: Operating temperature 0 to 50°C; storage temperature -20 to 60°C; humidity 10 to 90% RH (non-condensing).
- Certifications: CE, UL/cUL listed for industrial control equipment; RoHS compliant.
- Warranty: Standard 12-month warranty against manufacturing defects; extended options available upon request.
