The Allen-Bradley 2711P-K4M5D8 is a high-performance PanelView Plus 6 terminal engineered for demanding industrial automation applications. Featuring a vivid 15-inch color TFT active matrix display with 1024 x 768 resolution, this operator interface delivers exceptional clarity and touch sensitivity. The 2711P-K4M5D8 is equipped with a powerful 1.2 GHz dual-core processor, ensuring smooth navigation and rapid data updates even in complex HMI environments. With support for multiple industrial networks including Ethernet/IP, ControlNet, and DeviceNet, it integrates effortlessly into Rockwell Automation architectures. This terminal includes 512 MB of RAM and 512 MB of non-volatile flash memory, providing ample space for applications, trends, and alarms. The rugged design meets NEMA 4X/12 and IP66 front-panel standards, making it suitable for washdown and dusty environments. Standard communication ports include one RS-232 serial port, two USB 2.0 host ports, and one USB device port for programming and data transfer. The 2711P-K4M5D8 also features an integrated CompactFlash slot for removable storage and firmware upgrades. It supports a wide input voltage range of 24V DC (18-32V DC) and is certified for CE, UL, and CUL compliance.
| Specification |
Details |
| Product Type |
PanelView Plus 6 Performance Terminal |
| Display Size |
15 inches (diagonal) |
| Display Type |
Color TFT Active Matrix |
| Resolution |
1024 x 768 (XGA) |
| Touch Screen |
Analog Resistive Touch |
| Processor |
1.2 GHz Dual-Core |
| RAM |
512 MB DDR |
| Flash Memory |
512 MB Non-Volatile |
| Communication Ports |
1 x RS-232 (Serial), 2 x USB 2.0 Host, 1 x USB 2.0 Device |
| Network Support |
Ethernet/IP, ControlNet, DeviceNet |
| Expansion Slot |
1 x CompactFlash (Type I/II) |
| Input Voltage |
24V DC (18-32V DC) |
| Power Consumption |
36W (Maximum) |
| Enclosure Rating |
NEMA 4X/12, IP66 (Front Panel) |
| Operating Temperature |
0°C to 55°C (32°F to 131°F) |
| Storage Temperature |
-20°C to 70°C (-4°F to 158°F) |
| Relative Humidity |
5% to 95% Non-Condensing |
| Dimensions (H x W x D) |
Approximately 366 mm x 290 mm x 78 mm (14.4 in x 11.4 in x 3.1 in) |
| Weight |
Approximately 4.5 kg (9.9 lbs) |
| Certifications |
CE, UL, CUL, CSA |
| Mounting |
Panel Mount (Cutout Required) |
| Warranty |
Standard 2-Year (Extended Options Available) |
